0,047D2MRVP11-7,667-0(11k6x23) - Planetroll United States Sales

Please Contact Us to Order to offer best price and delivery time for Planetroll - 0,047D2MRVP11-7,667-0(11k6x23) planetroll control reducer number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Planetroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy 0,047D2MRVP11-7,667-0(11k6x23) by Planetroll in United States?

You can purchase 0,047D2MRVP11-7,667-0(11k6x23) by Planetroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the 0,047D2MRVP11-7,667-0(11k6x23)?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Planetroll in United States?

While we are not the official distributor or seller of Planetroll in United States, we source our products from reliable channels and offer you original Planetroll equipment at competitive prices.

How can I access 0,047D2MRVP11-7,667-0(11k6x23) catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 0,047D2MRVP11-7,667-0(11k6x23) on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 0,047D2MRVP11-7,667-0(11k6x23)?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification

BRAND	Planetroll
Product	0,047D2MRVP11-7,667-0(11k6x23)
Description	planetroll control reducer
Internal code	ONR4278769
Weight	3.4
Custom code	85015100
Technical specification	consisting of: --------------------- 1) Three-phase motor 2) Automatic transmission “p l a r o m a s t e r” 3) Control element 4) Planetary gearbox Dimension sheet: M070 802 specifications ------------------------- Mounting side: right Design: B14-like Installation position: 4 Speed range: 0 to approx. 145/174 rpm (50/60 Hz) Output torques: approx. 4.5 Nm from 7.8/9.4 to 26 rpm approx. 1.5/1.2 Nm at 145/174 rpm Weight: approx. 3.4 kg/pc Customs registration number: 8501 51 00 Drive components ------------------------------ 1 501-01220 1 PC three-phase motor 0.044/0.046 kW, 2600/3100 rpm, 230/400 V, 50/60 Hz, 0.27/0.16 A, IP 40, isol.kl.E, flange B14-62, centering diameter 25, shaft 9 x 25 mm. 2 302-00008 1 PC plaromaster type MRV variable speed transmission On the drive side: Ø9 hollow shaft with clamping element; centring Ø25, 4x Ø4.5 on TK36 output side: for mounting on type P11 planetary gears 3 302-00002 1 PC control element Type: HVN, rough scale 0-12, fine scale 0-100 4 301-00962 1 PC Planetary gearboxes type P11-0, reduction i = 7.667, 4x Bo.M4 on TK diameter 47, Output shaft diameter 11k6 x 23, (max.max. output torque M2=4.5 Nm).
