Please Contact Us to Order to offer best price and delivery time for Josef Emmerich - SP511S number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Josef Emmerich - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy SP511S by Josef Emmerich in United States?
You can purchase SP511S by Josef Emmerich from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the SP511S?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Josef Emmerich in United States?
While we are not the official distributor or seller of Josef Emmerich in United States, we source our products from reliable channels and offer you original Josef Emmerich equipment at competitive prices.
How can I access SP511S catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for SP511S on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for SP511S?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Josef Emmerich |
| Product | SP511S |
| Internal code | ONR4952475 |
| Weight | 370 |
| Technical specification | Piston diaphragm pump type: SP511S Design: simple-acting as a horizontal single-cylinder machine with vertical membrane housing Pump technical data: flow rate (m³/h): 4... 0, automatic regulation for filter press charging Delivery pressure (bar): 15 Piston diameter (mm): 120 Piston stroke (mm): 90 Stroke rate (min-1): 74 Valve design: ball valve with inspection opening and replaceable valve seat valve size DN: 50 Mitl. valve flow speed (m/s): 1.27 with a flow rate of 4 m³/h Pump head design: membrane housing with separate membrane housing cover for easy revision of the membrane, without that pipes and/or attachments must be dismantled Membrane design: Double membrane, designed as a large-sized flat membrane with integrated break indicator Components in contact with media: Pump housing and valves: cast iron Pulsation damper: steel, P235GH (St 37-2) Membrane: Perbunan (NBR), diameter 350 mm Valve seat: Vulkollan (polyurethane) Valve ball: Vulkollan with core, Ø 80 mm EK-A2-1245.2 1 FCA double membrane Stk (flat membrane) Ø 350 mm, Perbunan (NBR) Net weight per unit [kg]: 1,200 Product tariff no.: 40169997 Country of origin: DE 3 12338701 2 FCA valve seat Stk DN50, Vulkollan (PUR) Net weight per unit [kg]: 0.320 Product tariff no.: 84139100 Country of origin: DE 4 868001 2 FCA valve ball Stk Ø 80mm, polyurethane with core Net weight per unit [kg]: 1.234 Product tariff no.: 84139100 Country of origin: DE |
No documents...
Muzin 200 SF concentrate
Seaworthy wooden box
pump
concentrate
valve seat
pump stand
Bourdon tube pressure gauge
diaphragm rupture indicator with pressure switch
hydraulic oil
wooden base frame with foil coating
VALVE DRUM KIT
vent valve
overflow valve
valve seat
DIAPHRAGM PUMP NBR
Double pot cuff
piston diaphragm pump
valve ball
