MSX-W10-IN - Dwyer United States Sales

Please Contact Us to Order to offer best price and delivery time for Dwyer - MSX-W10-IN Differential Pressure Transmitter number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Dwyer - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy MSX-W10-IN by Dwyer in United States?

You can purchase MSX-W10-IN by Dwyer from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the MSX-W10-IN?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Dwyer in United States?

While we are not the official distributor or seller of Dwyer in United States, we source our products from reliable channels and offer you original Dwyer equipment at competitive prices.

How can I access MSX-W10-IN catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MSX-W10-IN on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MSX-W10-IN?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification
Document

BRAND	Dwyer
Product	MSX-W10-IN
Description	Differential Pressure Transmitter
Internal code	ONR4911067
Technical specification	Service Air and non-combustible, compatible gases Wetted Materials Consult factory Accuracy ±0.1% FSO Stability ±1% FSO/year Temperature Limits -4 to 158°F (-20 to 70°C) Pressure Limits Ranges 0 and 1: 3.6 psi max operation, 6 psi burst; Ranges 2 and 3: 6 psi max operation, 6 psi burst Power Requirements 10-36 VDC (2-wire), 17-36 VDC or isolated 21.6-33 VAC (3-wire) Output Signals 4-20 mA (2-wire); 0-10 V, 0-5 V (3-wire) Response Time Instantaneous (default) or 3 s (selectable) Zero and Span Adjustments Digital push-button Loop Resistance Current output: 0-1250 Ω max; Voltage output: min. load resistance 1 kΩ Current Consumption 21 mA max continuous Electrical Connections 4-wire removable European style terminal block for 16 to 26 AWG Electrical Entry ½" NPS thread Display (optional) 4 digit LCD Process Connections ⅛", 3/16", ¼", 5 mm, and 6 mm ID flexible tubing Enclosure Rating NEMA 4X (IP66); UL 2043 (Plenum); UL94 V-0 Mounting Orientation Pressure sensor measurement unaffected by orientation
