Please Contact Us to Order to offer best price and delivery time for LAIPPLE KEB - K33AV DM100LX4/2 B04 TS number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we LAIPPLE KEB - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy K33AV DM100LX4/2 B04 TS by LAIPPLE KEB in United States?
You can purchase K33AV DM100LX4/2 B04 TS by LAIPPLE KEB from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the K33AV DM100LX4/2 B04 TS?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of LAIPPLE KEB in United States?
While we are not the official distributor or seller of LAIPPLE KEB in United States, we source our products from reliable channels and offer you original LAIPPLE KEB equipment at competitive prices.
How can I access K33AV DM100LX4/2 B04 TS catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for K33AV DM100LX4/2 B04 TS on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for K33AV DM100LX4/2 B04 TS?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | LAIPPLE KEB |
| Product | K33AV DM100LX4/2 B04 TS |
| Internal code | ONR5009967 |
| Technical specification | Output speed: 115/232 1/min Torque: 200/128Nm Gear coefficient: 1.95/3.1 Gear unit: Ratio: 12.27 Foot mounted version Output shaft with key Ø30x60 Breather valve Mounting face : L Lubricant: 0.55 l CLP VG220 Mineraloil Motor: Pole changing motor Nominal power: 2.4/3.1kW Motor speed: 1410/2850 1/min Voltage/Frequency: Δ/YY 400V 50Hz Nominal current: 5.2/6.6A cosφ: 0.84/0.87 Insulation class: 155 Protection standard: IP54 Brake B04, 20Nm, 230VAC/105VDC Motor protection: Thermorelay (closed) Motor connection: terminal box 2xM25+1xM16, position 0A Paint: normal, RAL7031 bluegrey Mounting position: M1 |
