FKCW36V5-5XCEN-CW - Fuji United States Sales

Please Contact Us to Order to offer best price and delivery time for Fuji - FKCW36V5-5XCEN-CW Differential pressure transmitter number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Fuji - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy FKCW36V5-5XCEN-CW by Fuji in United States?

You can purchase FKCW36V5-5XCEN-CW by Fuji from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the FKCW36V5-5XCEN-CW?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Fuji in United States?

While we are not the official distributor or seller of Fuji in United States, we source our products from reliable channels and offer you original Fuji equipment at competitive prices.

How can I access FKCW36V5-5XCEN-CW catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for FKCW36V5-5XCEN-CW on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for FKCW36V5-5XCEN-CW?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification

BRAND	Fuji
Product	FKCW36V5-5XCEN-CW
Description	Differential pressure transmitter
Internal code	ONR3322427
Weight	4
Custom code	90262020
Technical specification	Smart, 4-20 mA dc + Fuji/HartTM digital signal Process connections : 1/4-18 NPT Oval flange connection : M10 or M12 (*1) Electrical connection : M 20 x 1,5 Enclosure type : L shape Span : 0,5 / 50 mWC Measuring diaphragm : 316L SS HP process cover : 316L SS and BP process cover : 316L SS Wetted cell body : 316L SS Indicator : digital, Custom scale with push-button Approvals (Note 1) : ATEX - Flameproof Side vent : None Mounting bracket : Yes, SS 304L TAG plate : Yes SS housing : Yes Special applications : NACE Fill fluid : silicone oil Process cover gasket : PTFE square section gasket in SS flange (FEF design) Bolts / Screws : SS 660/660 (bolt/nuts) M10 for static pressure < 160 bar Note 1 : Type of protection for use in hazardous areas ATEX -Flameproof Enclosure "d" Ex II 2G/D; Ex d IIC T5 Gb (-40°C = Ta = +85°C); Ex d IIC T6 Gb (-40°C = Ta = +65°C) Ex tb IIIC T100 °C Db (-40°C = Ta = +85°C) Ex tb IIIC T85°C Db (-40°C = Ta = +65°C); Vmax = 45 Vdc article reference: FKCW36V5-5XCEN-CW
