CES582M-00199 - TR Electronic United States Sales


Please Contact Us to Order to offer best price and delivery time for TR Electronic - CES582M-00199 Absolute encoder number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we TR Electronic - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy CES582M-00199 by TR Electronic in United States?

You can purchase CES582M-00199 by TR Electronic from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the CES582M-00199?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of TR Electronic in United States?

While we are not the official distributor or seller of TR Electronic in United States, we source our products from reliable channels and offer you original TR Electronic equipment at competitive prices.

How can I access CES582M-00199 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for CES582M-00199 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for CES582M-00199?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

BRAND TR Electronic
Product CES582M-00199
Description Absolute encoder
Internal code ONR5122667
Weight 0.4
Custom code 90318020
Technical specification

CES582M-00199

Absolute encoder
CES582M*8192/65536 CO DMS 14H7 KRF
Total weight 0.400 kg
Statistical product number: 90318020
Country of origin: GERMANY
Region of origin: Baden-Württemberg
AL:N
ECCN:N

Technical details appendix

Order number description

CES582M-00199 CES582M*8192/65536 CO DMS 14H7 KRF
STEP COUNT 8,192,000
REVOLUTIONS 65,536,000
CAN BE PARAMETERIZED VIA INTERFACE
CAN/OPEN INTERFACE
CODE BINARY
SUPPLY VOLTAGE 10-30V
PROTECTION CLASS IP65
WORKING TEMPERATURE -20°C... +75°C
FLANGE TYPE DMS 2 WING DIVIDER 63
TORQUE SUPPORT (DMS)
SHAFT VARIANT HOLLOW SACK SHAFT
D14H7 SHAFT DESIGN
Connection type 1x M12 05-PIN A-CODE FEMALE

1x M12 05-PIN A-CODE MALE

RADIAL CONNECTION DIRECTION
PIN ASSIGNMENT NUMBER TR-ECE-TI-DGB-0339
OPTION ENC TERMINATING RESISTOR: ONE
CANOPEN BAUD RATE: 250K
CANOPEN NODE ID: 63
FLANGE-SIDE CLAMPING RING
DRAWING NUMBER 04-CES582M-M0160
AL: N
ECCN: N
mTTFd [y] (T=45°C, DC=0) >= 100
UL APPROVALS USA+CANADA
