Please Contact Us to Order to offer best price and delivery time for Stahl - 214171 / 8150/5-V37-302-50-0010 Safety switch 16 A, explosion-proof number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Stahl - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy 214171 / 8150/5-V37-302-50-0010 by Stahl in United States?
You can purchase 214171 / 8150/5-V37-302-50-0010 by Stahl from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the 214171 / 8150/5-V37-302-50-0010?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Stahl in United States?
While we are not the official distributor or seller of Stahl in United States, we source our products from reliable channels and offer you original Stahl equipment at competitive prices.
How can I access 214171 / 8150/5-V37-302-50-0010 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 214171 / 8150/5-V37-302-50-0010 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 214171 / 8150/5-V37-302-50-0010?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Stahl |
| Product | 214171 / 8150/5-V37-302-50-0010 |
| Description | Safety switch 16 A, explosion-proof |
| Internal code | ONR4450715 |
| Weight | 3.25 |
| Custom code | 85371098 |
| Technical specification | Rated operating voltage AC: 690 V Rated operating current: 16 A Housing material: stainless steel 1.4404 (AISI 316L), brichgesc Detailed number of pins: 3-pin Auxiliary contact opener: without Auxiliary contact normally open: 1 normally open contact/lagging Additional clamp: standard (without) Area of application (zones): 1, 2, 21, 22 gas explosion protection: II 2 G Ex db eb IIC T6 Gb Dust Explosion Proof: II 2 D Ex tb IIIC T80°C Db Ambient temperature min. ፦40°C Max. ambient temperature: +50 °C special conditions for extended ambient temperature, see operating instructions: Extended ambient temp min. ፦40 °C Extended ambient temp. max.: +65 °C Protection class (IP): IP66 Cable entry: 2 x M25 Ø 7... 17 mm 1 x M20 Ø 4... 13 mm Connection cross section: 2.5... 6 mm2 Connection cross section HIKO: 1.5... 4 mm2 fine stranded 1.5... 6 mm2 single wire Replacement for material: 147875 |
No documents...
P/N: 145317, Type: 8493/11-21-6
signaling device
SAFETY SWITCH/ 25 A, 3-POLE
P/N: 149135, Type: 8560/51-4061
small safety element
P/N:149164, Type: 8560/51-4222
Small fuse element
P/N: 150598, Type: 8570/11-304
Switch socket
Switch socket
Switch socket
(Switch socket explosion proof)
P/N: 150494, Type: 8570/11-506
Switch socket
Stecker
plug
Plug explosion-proof
(Plug explosion Proof Type: 8570 / 12-406 Bemessungsbetr.spg. / Frequency: 380-415 V 50/60 Hz Operating current: 16 A Detailed Contacts 4 P (3 P + PE) Color code: red Coding (time position): 6 Housing material: Polyamide Field of Application (zones): 1, 2, 21, 22 Gas explosion protection: II 2 G Ex de IIC T6 Dust explosion protection: II 2 D IP66 80 ° C Ambient temperature min. : -30 ° C Ambient temperature max. +55 ° C Protection (IP): IP66 Terminals: 1.5 mm Cable entry: 8 ... 20 mm plug explosion proof)
P/N: 150854, Type: 8571/11-506
switch socket
P/N: 150855, Type: 8571/12-506
Plug; Explosion-protected
PLUG,UTILITY, 2-POLES
Flange socketexplosion-protectedType : 8575/15-306Rated oper.voltage / Frequency: 200-250 V 50/60 HzRated operational current : 16 ADetailed number of poles : 3 P (2 P + PE)Identification colour : blueCoding (clock hour position) : 6Enclosure material : Polyester resinApplication range (Zone) : 1 , 2Min. ambient temperature : -20 °CMax. ambient temperature : +40 °CType of protection (IP) : IP54
p/n: 270900, Type: 8579/31-506
Switch socket for low temperature, explosion-proof
Pushbutton
(Button label Label marking : STOP Colour of label : red For further information, see : www.r-stahl.com Web code 8082A)
(Rotary handle, small lockable explosion-protected Enclosure material : Polyamide Seal : Standard Mounting : with threaded Switching function : latching Number of switching positions : 2 Construction type : vertical Application range (Zone) : 1 , 2 , 21 , 22 Gas explosion protection : II 2 G Ex e II Dust explosion protection : II 2 D Ex tD A21 Min. ambient temperature : -50 °C Max. ambient temperature : +70 °C Type of protection (IP) : IP66 For further information, see : www.r-stahl.com Web code 8082A)
8703-PUSH BUTTON ASSEMBLY (OBSOLETE REPLACED BY 8602)
PUSH BUTTON FOR START-NO CONTACT
Max. Voltage Uo : 28 VMax. Current Io : 100 mAMax. Demand Po : 700 mWNumber of channels : 1Polarity : negative polarityApplication range (Zone) : 2Gas explosion protection : II 3 (1) G Ex nA[ia Ga]Dust explosion protection : II (1) D [Ex ia Da] IIICRated operational voltage DC : 24 VMaximum output current Imax : 75 mAFor further information, see : www.r-stahl.com Web code 9001A
Single-channel safety barriers explosion-protected
