8074/2-1-WH-40 - R.Stahl United States Sales

Please Contact Us to Order to offer best price and delivery time for Stahl - 8074/2-1-WH-40 Position switch explosion proof number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.

WE SELL ONLY ORIGINAL AND NEW PRODUCTS!

Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners

Important note: Although we Stahl - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.

Where can I buy 8074/2-1-WH-40 by Stahl in United States?

You can purchase 8074/2-1-WH-40 by Stahl from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.

What is the price of the 8074/2-1-WH-40?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Stahl in United States?

While we are not the official distributor or seller of Stahl in United States, we source our products from reliable channels and offer you original Stahl equipment at competitive prices.

How can I access 8074/2-1-WH-40 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for 8074/2-1-WH-40 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for 8074/2-1-WH-40?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.

Technical specification
Document

BRAND	R.Stahl
Product	8074/2-1-WH-40
Description	Position switch explosion proof
Internal code	ONR3416973
Weight	0.404
Custom code	85389099
Technical specification	T.assi. AC (identical potential): 400 V T.assi. AC (differential potential): 250 V Rated operational voltage DC: 125 V Rated operating current: 4.4 A Version: 2nd generation Contacts: 1 NC + 1 NO Degree of protection (IP): IP66 Area of application (zones): 1 , 2 , 21 , 22 Protect. against gas explosion: II 2 G Ex de IIC T6....T5 Gb Protect. against expl. dust: II 2 D Ex tb IIIC T80 °C ....T95 °C Db Contact material: Silver-nickel Housing material: Resistive aluminium. to corr., rev. pood. Number of NCs: 1 Number of NOs: 1 Actuator: Roller lever Switch function: Slow action contact Freq. maximum operation: 1800 operating cycles/h Electrical life: max. 10^6 operating cycles Cable glands: 1 x M20 Ø 4 – 13 mm Clamping range: 4 ... 13 mm
