Please Contact Us to Order to offer best price and delivery time for Planetroll - 0,37D4(Ex)MR3-2(160,19h6x40) no eyelets three-phase motor number, also you may ask some other model number is well. We can offer best price, and delivery time with wide products distribution network in United States Industrial products Market.
WE SELL ONLY ORIGINAL AND NEW PRODUCTS!
Our company is not an authorized distributor and manufacturer's representative of the brands shown on the website. Private brand names shown on this site and trademarks are the property of their respective owners
Important note: Although we Planetroll - Products are Onrion LLC not an authorized dealer. All rights are reserved by the manufacturers and their official partners.
Where can I buy 0,37D4(Ex)MR3-2(160,19h6x40) no eyelets by Planetroll in United States?
You can purchase 0,37D4(Ex)MR3-2(160,19h6x40) no eyelets by Planetroll from Onrion LLC. We serve customers across United States, offering competitive prices and reliable service.
What is the price of the 0,37D4(Ex)MR3-2(160,19h6x40) no eyelets?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Planetroll in United States?
While we are not the official distributor or seller of Planetroll in United States, we source our products from reliable channels and offer you original Planetroll equipment at competitive prices.
How can I access 0,37D4(Ex)MR3-2(160,19h6x40) no eyelets catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 0,37D4(Ex)MR3-2(160,19h6x40) no eyelets on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 0,37D4(Ex)MR3-2(160,19h6x40) no eyelets?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
| BRAND | Planetroll |
| Product | 0,37D4(Ex)MR3-2(160,19h6x40) no eyelets |
| Description | three-phase motor |
| Internal code | ONR4470804 |
| Weight | 22 |
| Custom code | 85015100 |
| Technical specification | consisting of: a) three-phase motor b) control gear “p l a r o m a s t e r” Control element: right Design: B5 (engine terminal box left) Installation position: 4 (V1) Speed range: 0 to approx. 500 rpm ** Output torques: approx. 7 Nm from 10 to 320 rpm approx. 5.2 Nm at 500 rpm ATEX design: Ex II 2 G Ex h IIB T4 Gb (drive unit) 1 202-00477 Internal mechanical speed limitation 501-01752 drive-side: 3-phase motor 0.37 kW, 1390 rpm, 230/400 V +/- 5%, 50 Hz, 1.7/0.98 A, IP 55, isol.class F, “Increased safety” Exii2g Exe IIC T4 Gb+ with IBEXU02ATEX1112-09; aluminum terminal box, 1x M20x1.5 cable entry; size 80, connection size 71, B14/V18-105 with protective roof 302-07451 PLAROMASTER control gear unit type MR3 - silicone-free drive-side: for motor mounting, size 71, B14-105 (with lantern and coupling) output side: B5 flange dia.160 with leakage control, output shaft Ø19H6 x 40 302-01466 Control element type HVK 5 for AR2-AR5/MR3+MR5: Handwheel (d0=50) with fine adjustment scale; coarse scale 0 - 12, fine scale 0 - 100 602-08882 + paint RAL 9010 -pure white- |
